Overview
Not just for live bands and DJ's, the MG Series mixing consoles can easily adapt to a truly impressive range of applications from portable PA to fixed installation. Now with the newly added digital functions and superior sound of the MGP, the possibilities are endless.
Finance
Bring the dream within easier reach by spreading the cost with V12 Retail Finance. With a range of different finance schemes available, use the Finance Calculator below to choose a deposit amount and find out possible monthly payments.
Click here for more information
Finance agreements are available to UK residents aged 18 or over, subject to status.
Thank you for choosing V12 Retail Finance; you will now be taken to V12 Retail Finance's website to complete your finance application.
Yamaha Music Europe GmbH (UK) trading as Yamaha Music London is registered in England and Wales BRO14498 at Sherbourne Drive, Tilbrook MK7 8BL. Yamaha Music Europe GmbH (UK) trading as Yamaha Music London acts as a credit broker and offers credit products from Secure Trust Bank PLC trading as V12 Retail Finance. Yamaha Music Europe GmbH (UK) trading as Yamaha Music London is authorised and regulated by the Financial Conduct Authority. Yamaha Music Europe GmbH (UK) FCA registration number is FRN688040. Credit provided subject to age and status.
V12 Retail Finance is registered in England and Wales with company number 4585692. Registered office: Yorke House, Arleston Way, Solihull, B90 4LH. Authorised and regulated by the Financial Conduct Authority (FCA). V12 Retail Finance's FCA reference number is 679653.
Features
The MGP32X has the following features:
- 24 Mic Inputs with 48V Phantom Power and HPF per Channel
- 32 Line Inputs (24 mono and 4 stereo)
- 6 AUX Sends + 2 FX Sends
- 4 GROUP Buses + ST Bus
- 2 Matrix out
- 1 Mono out
Specs
Outline
| Mixing capability | Mixing channels | 32 Line Inputs (24 mono and 4 stereo) |
|---|
| GROUP | 4 GROUP Buses + ST Bus |
|---|
| AUX | 6 AUX Sends + 2 FX Sends |
|---|
| MATRIX | 1 Matrix out |
|---|
| On-board processors | FX1:REV-X(8 PROGRAM, PARAMETER control)/ FX2:SPX(16 PROGRAM, PARAMETER control) |
|---|
| I/O | Mic inputs | MIC: 24 (INPUTS HPF: 100Hz 12dB/oct) |
|---|
| Phantom power | 48V phantom power per channel |
|---|
| Line inputs | LINE: 24 mono + 4 stereo, CH INSERT: 24 RETURN: 1 stereo |
|---|
| Digital I/O | USB Device, iPod / iPhone |
|---|
General specifications
| Total harmonic distortion | 0.02% (20Hz-20kHz@ +14dBu) |
|---|
| Frequency response | +0.5/-1.0dB 20Hz - 20kHz, refer to the nominal output level @1kHz |
|---|
| Hum & noise level | Equivalent input noise | -128 dBu Equivalent Input Noise |
|---|
| Residual output noise | -94 dBu Residual Output Noise |
|---|
| Crosstalk | -74dB @ 1kHz |
|---|
| Power requirements | 100-240V 50Hz/60Hz |
|---|
| Power consumption | 86W max |
|---|
| Dimensions | W | 1,027mm (40.4") |
|---|
| H | 169mm (6.7") |
|---|
| D | 565mm (22.2") |
|---|
| Net weight | 19kg (41.9lb) |
|---|
