Overview
7.5 inch Snare/Tom pad with 3-zones (Open/Closed rimshot capable)
Features
A newly developed 7.5-inch rubber Snare/Tom pad with 3-zones and a shape that is compact but easy to hit.
Through the experience of developing Yamaha's well-known DTX-PAD, this rubber pad provides much greater playability. It features a softer head to provide moderate bounce, and the surface is not slippery to give a more natural feeling when playing with sticks.
The pad is divided into 3-zones and supports open and closed rimshots when used with a compatible DTX trigger input*.
This pad makes a perfect snare upgrade for the DTX430K and DTX400K.
In addition, you can assign different voices to different zones (DTX500/700/900/M12 only). This makes highly original performances possible. For example, you can create an acoustic drum sound when you hit the head area, a cowbell sound when you hit the open rim area, and a loop sound when you hit the closed rim area.
* Before you purchase a pad, refer to the pad compatibility table to make sure that you can connect the pad to your drum trigger module (tone generator).
♦ Standard-equipped on the following DTX drums: DTX450K
Specs
Size/Weight
- Dimensions Diameter 220 (dia.:7.5") x 68 mm (not including S wing bolt)
- Weight Weight 0.9 kg (including S wing bolt)
PAD
- Zone 3 (Head/Open Rim/Closed Rim)
- PAD surface Rubber Head
- Available for Snare and Tom Pad
- Tom mount hole Yes
- Pad Controller No
- Connections Standard stereo-audio jack
- Package Contents TP70S pad (x1), S wing bolt (x1), Stereo audio cable (×1), Owner’s Manual
| Product ID | JTP70S |
|---|
| Limited Shipping |
|
