Overview
Yamaha YEP-642T Neo Euphonium with Trigger System
Working together with world-renowned brass band conductor Bill Millar, our Euphonium makers started with a clean slate creating numerous prototypes, redesigning each part and component until all were convinced that the perfect brass band sound we sought had been attained. The YEP-642 euphonium delivers a tone that blends well with baritone and tenor horns. Powerful with excellent projection, it produces the tonal colour that soloists seek in an instrument.
For the YEP-642T, we added a main-tube trigger system to offer enhanced, precise pitch control.
Finance
Bring the dream within easier reach by spreading the cost with V12 Retail Finance. With a range of different finance schemes available, use the Finance Calculator below to choose a deposit amount and find out possible monthly payments.
Click here for more information
Finance agreements are available to UK residents aged 18 or over, subject to status.
Thank you for choosing V12 Retail Finance; you will now be taken to V12 Retail Finance's website to complete your finance application.
Yamaha Music Europe GmbH (UK) trading as Yamaha Music London is registered in England and Wales BRO14498 at Sherbourne Drive, Tilbrook MK7 8BL. Yamaha Music Europe GmbH (UK) trading as Yamaha Music London acts as a credit broker and offers credit products from Secure Trust Bank PLC trading as V12 Retail Finance. Yamaha Music Europe GmbH (UK) trading as Yamaha Music London is authorised and regulated by the Financial Conduct Authority. Yamaha Music Europe GmbH (UK) FCA registration number is FRN688040. Credit provided subject to age and status.
V12 Retail Finance is registered in England and Wales with company number 4585692. Registered office: Yorke House, Arleston Way, Solihull, B90 4LH. Authorised and regulated by the Financial Conduct Authority (FCA). V12 Retail Finance's FCA reference number is 679653.
Features
Body Design
The YEP-642T's main tube utilises a new design that maintains adequate resistance, delivers a powerful low range and focused high range, and improves dynamics over the instrument’s entire range. In addition to a matured and comfortable tone, this design offers accurate pitch while delivering greater musical expressiveness.
Handrest
Changing the handrest position to allow for a more natural hold on the instrument simplifies fingering and offers smoother performance while playing demanding solo or ensemble passages.
Main Tube Trigger System
A main-tube trigger system offers precise pitch control as well as solid tone. The lever plate can be pressed during a performance to shift the main tube tuning slide downward, lowering pitch by a precisely controlled amount. Release the lever plate and the tuning slide returns to its original position. To tune the instrument prior to a performance, loosen the rod base screw so that the main tube tuning slide can be positioned as required. The screw can then be tightened to set the trigger rod to the desired position.
*A hex wrench (for lever plate vertical position and angle adjustment) and operation manual for the trigger system are supplied.
Adjustable Trigger System
The position, angle, and stroke of the lever plate can be adjusted to optimize trigger system operation and comfort individual needs:
- Lever plate vertical position and angle adjustment: The supplied hex wrench can be used to loosen the lever plate screws, allowing the vertical position and angle of the lever plate to be adjusted for maximum operation comfort and ease.
- Lever plate stroke adjustment: Use a standard “minus” screwdriver to rotate the lever plate stroke screw and adjust as required.
Dedicated Main Tube Trigger Slide
The main tube tuning slides of euphoniums designed for trigger mechanisms have a rod base to which the trigger rod attaches. Additionally, the diameter of the main tube tuning slide inner tube is smaller than normal to ensure smooth trigger operation.
Dedicated Main Tube Tuning Slide Trigger Cover
A special metal cover prevents the main tube tuning slide from coming into to direct contact with and possibly transferring oil to the player’s clothing. Loosen the attachment screw to adjust the position of the cover as required.
Specs
Key | Bb |
Body | Yellow brass |
Bell Diameter | 300mm (11 4/5") |
Bore Size | 15-16.8mm (0.591-0.661") |
Height | 664mm |
Valves | 3 top + 1 side, compensating |
Finishes | Clear lacquer and Silver-Plated |
Mouthpiece | SL-51L |
Case | Included |
